There are two device – mounting methods. Before installation, ensure the device is fully charged.

Use screws:

Place the hole – positioning sticker at the doorbell installation position, align and drill holes, then insert the expansion tube anchor (remove the sticker after drilling).

Secure the base to the wall with screws.

Align the device's mounting bracket holes with the base's, and press the device into the buckles.

Use adhesive tape:

Attach 3M adhesive tape to the back of the mounting bracket and stick it on the wall at the desired position (clean the wall surface first).

Align the mounting holes on the bracket and press the device into the buckles." "How to Add Device?

1. You can search CamVigil APP in the app store /Google Play store.

2. Registration, Login, and Password Reset

3.Adding Devices

On the CamVigil homepage, click the “+” icon or the “Add A Device” button, select your device type, and follow the network connection configuration process." "The device cannot connect to WiFi

1. Please ensure that the wireless network uses the 2.4G.

2. Ensure that the indicator light flashes after the device is reset

3. Check whether the password is correct and ensure there are no extra spaces

Smart Video Doorbell Parament

Indoor/Outdoor Usage:Outdoor/Indoor

Compatible Devices:‎Laptop, Tablet, Smartphone

Power Source:‎Battery Charge

Controller Type:Push Button, Phone

Video Capture Resolution:‎1920 x 1080p

Wireless Communication Technology:‎Bluetooth,2.4G Wi-Fi

Effective Video Resolution:‎1080

Viewing Angle:120° diagonal, 90° horizontal, 56° vertical

Installation Type:‎Wall Mounting

Night Vision Range:30 Feet

Temperature Rating:‎-10 – 50 Degrees Celsius

Frame Rate:‎15 frames_per_second

Material:‎Plastic

Product dimensions:‎1.32 x 2.13 x 6.42 inches

Water Resistance Level:‎IP 65

Room Type:‎Office, Kitchen, Living Room, Classroom

Video Capture Format:MP4

Specific Uses For Product:‎Surveillance

Control Method:‎Voice

Batteries:1 Lithium Ion batteries required.         (included)

Special Features:‎HD Resolution, 2-Way Audio, Night Vision, Noise Reduction, Brightness Control, Time-Lapse

Item Package Quantity:‎1

• Works with Alexa — receive alerts and answer with two-way audio. When wired or paired with a Sync Module, just ask Alexa to answer the front door.
• Full HD 1080p HDR with two-way talk to answer your door and talk to your guests from anywhere live through your smartphone, tablet. Works with App
• Advanced radar verification, motion, person, and package detection, and activity zones, so you only get alerts for who or what is at your door.
• Industry-leading, head-to-toe field of view, so you can see everything – day or night. With Smart Focus, auto-pan allows for a closer, clearer view of visitors or packages at your door with an expansive 91° vertical and 120° diagonal field of view.
• It can work in heat, cold, rain, or snow.Because of its wired configuration, and with IP65 waterproofing and dust protection, it can operate between -10 and 50°C (14 and 122°F) without losing power.
• Maximum standby time 180 days, maximum usage time 60 days (varies according to settings, usage and temperature)
• PIR human body sensing wake-up, key wake-up, remote active wake-up, video recording mode for key triggering, infrared sensor triggering, through the hand phone APP message push to alarm notification.
